TuffX Frameless Flat Rooflight 600 x 600mm

The TuffX Frameless Flat Rooflight 600 x 600mm combines high-performance double glazing with a clean, minimalist design. The frameless external glass edge provides a modern appearance with no visible external frame, making it suitable for contemporary flat-roof installations, extensions and renovations.

Manufactured using advanced glass-bonding technology, the rooflight provides a durable and weather-resistant glazing solution while maximising the glazed viewing area. The low-profile external design allows rainwater to run freely from the glass surface.

Frameless Flat Rooflight 600 x 600mm

The supplied insulated kerb provides a 150mm upstand and simplifies installation above the roof level. The kerb also helps provide correct positioning and drainage for the rooflight.

For effective water run-off, the rooflight requires a minimum roof pitch of 5°.

Key Features

• Rooflight size: 600mm x 600mm
• Minimum roof opening: 600mm x 600mm
• External kerb size: 760mm x 760mm
• Kerb height: 150mm
• Glazing: Double-glazed high-performance safety glass
• Glass centre pane U-value: Approx. 1.2 W/m²K
• Minimum roof pitch: 5°
• External finish: Frameless clear glass edge design
• Insulated kerb: Supplied

Modern Frameless Rooflight Design

The frameless external design creates a clean glass finish that complements modern building projects. Internally, the slimline structure maximises the glazed viewing area while providing the support required for the rooflight.

Applications

The TuffX 600 x 600mm frameless flat rooflight is suitable for a range of flat-roof projects, including:

• Modern extensions
• Kitchen extensions and renovations
• Flat-roof installations
• Replacement of older rooflights
• Contemporary residential projects

Installation Requirements

The minimum roof pitch for the frameless rooflight is 5°, as specified for effective water drainage and run-off. The supplied 150mm insulated kerb is designed to sit above roof level and assist with positioning and weatherproofing.

Technical Specification
