Made-to-Measure Aluminium 3-Pane Bi-Fold Door – Superior Thermal Performance with Custom Finishes
- Brand: Master Plastics
- Product Code: SHEERLINE3
- Availability: In Stock
3 Pane Aluminium Bi-Fold Doors - Made to Measure Bristol
Our 3 Pane Aluminium Bi-Fold Doors combine slim contemporary aluminium styling with excellent thermal performance, large glazed areas and flexible opening configurations.
Made to measure in Bristol, each aluminium bi-fold door is manufactured to your required dimensions, with a choice of frame colours, hardware, sash styles, thresholds and glazing options.
Available from 1800mm to 3000mm wide and up to 2400mm high, the three-panel configuration is ideal for extensions, renovations and new-build projects where you want to create a wide connection between your home and garden.
Made-to-Measure 3 Pane Aluminium Bi-Fold Doors
Every door is manufactured to order rather than supplied in fixed standard sizes. Enter your required width and height and select the configuration and finishing options required for your project.
- Minimum Width: 1800mm
- Maximum Width: 3000mm
- Minimum Height: 2020mm
- Maximum Height: 2400mm
- Configuration: 3 Pane / 3 Sash
- Material: Aluminium Composite System
- Manufacture: Made to Measure
Thermally Efficient Aluminium Bi-Fold Door
The system combines the appearance and durability of aluminium with a full-width thermal core designed to significantly improve thermal performance compared with traditional non-thermally broken aluminium systems.
This construction helps reduce heat transfer through the door frame while retaining the slim appearance associated with modern aluminium doors.
28mm Double Glazing as Standard
The standard door specification includes 28mm toughened double glazing, providing a combination of safety, thermal performance and large uninterrupted glazed areas.
- Standard Glass: 28mm Toughened Double Glazing
- Standard U-Value: Approximately 1.4 W/m²K
44mm Triple Glazing Upgrade
For projects requiring enhanced thermal performance, the door can be upgraded to 44mm triple glazing.
Depending on the complete door specification, the upgraded system can achieve a U-value of approximately 1.0 W/m²K.
This makes triple glazing particularly attractive for new-build properties, extensions and energy-efficient renovation projects.
3 Pane Bi-Fold Door Opening Options
The three-panel design provides several opening configurations. Select the required arrangement when ordering to suit the position of the door and the way you want to use the opening.
Options include:
- Left-Hand Configuration - viewed from outside
- Right-Hand Configuration - viewed from outside
- French Door Style Configuration
- Internal Folding
- External Folding
Please check the selected opening and folding direction carefully before placing your order.
Aluminium Bi-Fold Door Colours
Choose from a selection of popular aluminium frame colours to complement both contemporary and traditional properties.
- Pure White
- Heritage Cream
- Jet Black
- Anthracite Grey
These standard colour options are available without an additional colour surcharge.
Choice of Door Hardware
Complete the appearance of your aluminium bi-fold doors with a choice of hardware finishes:
- Matt Black
- Satin Silver
- Brushed Graphite
Choose Your Sash Style
The door can also be personalised with a choice of sash profile styles:
- Pencil Round
- Decorative
- Square
- Chamfered
This allows you to choose a finish that complements the style of your property and other windows and doors.
Standard or Low Aluminium Threshold
Choose between the standard entrance threshold or upgrade to a low aluminium threshold where a lower step is preferred and the installation conditions are suitable.
Cill options are also available to suit different installation requirements.
Ideal for Extensions & Renovations
A 3 pane aluminium bi-fold door provides a large glazed opening without requiring the width needed for four, five or six-panel systems.
This makes the three-panel configuration particularly suitable for:
- Kitchen extensions
- Kitchen-diners
- Living rooms
- Garden rooms
- Orangeries
- New-build properties
- Home renovations
- Replacement patio doors
- Replacement French doors
Aluminium Bi-Fold Doors Bristol
We manufacture and supply made-to-measure aluminium bi-fold doors in Bristol for homeowners, builders, property developers and trade customers.
If you are looking for aluminium bi-fold doors in Bristol, our made-to-measure service allows you to configure the size, opening arrangement, colour, glazing, hardware and threshold required for your project.
Our doors are available for projects throughout Bristol and the surrounding area, with delivery options also available for customers elsewhere in the UK.
3 Pane Aluminium Bi-Fold Door Specifications
- Product: 3 Pane Aluminium Bi-Fold Door
- Number of Panels: 3
- Minimum Width: 1800mm
- Maximum Width: 3000mm
- Minimum Height: 2020mm
- Maximum Height: 2400mm
- Construction: Aluminium with Full-Width Thermal Core
- Standard Glazing: 28mm Toughened Double Glazing
- Triple Glazing Option: 44mm
- Standard U-Value: Approximately 1.4 W/m²K
- Triple Glazed U-Value: Approximately 1.0 W/m²K depending on specification
- Folding Direction: Internal or External
- Frame Colours: Pure White, Heritage Cream, Jet Black or Anthracite Grey
- Hardware: Matt Black, Satin Silver or Brushed Graphite
- Sash Styles: Pencil Round, Decorative, Square or Chamfered
- Threshold: Standard or Low Aluminium Threshold
- Manufacture: Made to Measure
Ordering Your Made-to-Measure Bi-Fold Doors
Enter the required width and height and select your preferred opening configuration, folding direction, frame colour, hardware, sash style, glazing and threshold options.
As every door is manufactured to order, please check all measurements and configuration choices carefully before placing your order.
If you require a size or configuration outside the options shown online, please contact us to discuss your requirements.
