Made to Measure DIY Porch
2.5m X 2.0m Edwardian DIY Porch UPVC Made To Measure
Made to Measure Edwardian Porch 2.5m X 2.0m
All of our Edwardian style porches are supplied made to measure at no extra charge. Standard roofs are manufactured from strong clear multi wall polycarbonate roof sheets but you can also select bronze or opal polycarbonate roof sheets.
You can also choose to upgrade your roof to a glass roof. Roof glass is available in standard roof glass or low energy self cleaning glass in clear or blue tinted.
Prices shown do not include opening windows but you can upgrade to up to 4 opening windows. You can also add a letter box.
Door and window furniture is supplied in white as standard.
External frame projection size = internal size plus 70mm x width external frame size = internal size plus 140mm Price excludes any opening windows . Sizes given are external brick work sizes.
Edwardian porches are made to measure if you require a size smaller please enter the external brick work size width x projection.
2.5m wide x 2.0m Edwardian Porch With full height, half glazed panels.
Ply-reinforced lower panels at a standard height of 600mm and 150mm wide cill
Quality door furniture including hinges, lever/lever door handle, lock key. (Optional Letter box)
Low-e toughened, argon filled double glazed units.
Front frame height up to eaves beam 2100mm.
Ridge height needs approx 2.750mm from DPC.
Options:
- Width: Enter the external width required in the box on the right. (up to 2.5m)
- Projection: Enter the external projection required in the box on the right. (up to 2.0m)
- Roof Glazing: Select from 25mm polycarbonate or glass
- Opening top windows: Select the quantity you require.
- Frame Colour: Choose from White, Light Oak or Rosewood.
- Letter Box: Select if required.
- Door Position: Looking from the front, choose the position of the door, Left or Right Projection, or front Left, Right or Centre
- Door Furniture Colour: Select from White, Chrome or Gold.
- Door Positioning & Opening: Select the location of the door and whether it opens in or out.
- Cylinder 1 star: The one Star locking cylinder is our anti pick stand lock cylinder
- Cylinder 3 Star; The 3 Star locking cylinder is our most secure locking system we offer.
- Delivery Service - If you do not have personnel available for unloading the lorry. Please select 2 man delivery in the options. This is a surcharge in addition to the normal delivery charge.
Installation Guide - Click Here
1.5m X 1.5m Edwardian DIY Porch UPVC Made To Measure
Made to Measure Edwardian Porch 1.5m X 1.5m
All of our Edwardian style porches are supplied made to measure at no extra charge. Standard roofs are manufactured from strong clear multi wall polycarbonate roof sheets but you can also select bronze or opal polycarbonate roof sheets.
You can also choose to upgrade your roof to a glass roof. Roof glass is available in standard roof glass or low energy self cleaning glass in clear or blue tinted.
Prices shown do not include opening windows but you can upgrade to up to 4 opening windows. You can also add a letter box.
Door and window furniture is supplied in white as standard.
External frame projection size = internal size plus 70mm x width external frame size = internal size plus 140mm Price excludes any opening windows . Sizes given are external brick work sizes.
Edwardian porches are made to measure if you require a size smaller please enter the external brick work size width x projection.
1.5m wide x 1.5m Edwardian Porch With full height, half glazed panels.
Ply-reinforced lower panels at a standard height of 600mm and 150mm wide cill
Quality door furniture including hinges, lever/lever door handle, lock key. (Optional Letter box)
Low-e toughened, argon filled double glazed units.
Front frame height up to eaves beam 2100mm.
Ridge height needs approx 2.750mm from DPC.
Options:
- Width: Enter the external width required in the box on the right. (up to 1.5m)
- Projection: Enter the external projection required in the box on the right. (up to 1.5m)
- Roof Glazing: Select from 25mm polycarbonate or glass
- Opening top windows: Select the quantity you require.
- Frame Colour: Choose from White, Light Oak or Rosewood.
- Letter Box: Select if required.
- Door Furniture Colour: Select from White, Chrome or Gold.
- Door Positioning & Opening: Select the location of the door and whether it opens in or out.
- Cylinder 1 star: The one Star locking cylinder is our anti pick stand lock cylinder
- Cylinder 3 Star; The 3 Star locking cylinder is our most secure locking system we offer.
- Delivery Service - If you do not have personnel available for unloading the lorry. Please select 2 man delivery in the options.
Installation Guide - Click Here
At the heart of WarmCore products is a thermal core which significantly out-performs the polyamide thermal breaks commonly used to reduce the threat of cold bridging on aluminium windows and doors. The result is an innovative 'warm aluminium' frame construction, carefully dimensioned to provide an optimised 70mm front-to-back overall sash frame depth while ensuring market-leading thermal performance thanks to the multi-chambered insulating core.
Silicone, Sealants & Glue
Soudal Black Silicone
- Neutral Silicone
- Low Modulus
APPLICATION
Premium grade, one part, neutral curing, silicone sealant for glazing, constructions and industrial applications. Perimeter sealing of wood, PVCu and aluminium widnow and door frames. Sealing of roofline and drainage systems. Weathersealing of aluminium glazing systems, curtain walling and facade panels. Can be used in direct contact with all types of glass, except self-cleaning types (use SOUDAL SMX 506 for this application). Bedding of double glazed sealed units in wet glazing applications*. Sealing of expansion and movement joints in construction. roofing seals including lead roofing slates, and fibre-cement. Industrial sealing applications; coated metals, anodized aluminium, stainless steel. HVAC ducting, pipework, and drainage joints. general maintenance and sealing of cars, caravans, mobile homes and boats.
*Due to the number of sealed unit sealants available, a prior compatibility test is recommended.
CHARACTERISTICS
Fast curing neutral silicone (very low dirt pick up).
Solvent free silicone, no shrinkage during curing. Virtually odourless. Thick-bodied formulation for ease of use. Excellent break off and tooling, Excellent primerless adhesion on all common construction materials, (glass, plastics, masonry substrates, metals and wood). For natural stone applications we recommend the use of SILIRUB MA. Resistant to UV, rain, snow and ozone, and many chemicals. Low modulus of elasticity, high movement capability. Independently tested to ISO 11600 F&G 25 LM standard (test reports - IFT Rosenheim 504 35398/1, 504 35398/2. High and low temperature resistance (from -40ºC up to 200ºC).
DIRECTIONS FOR USE
Surfaces to be sealed must be dry, clean and free of dust, grease and other contaminants. Apply at temperatures between +5ºC and +40ºC. for more detailed information consult the technical data sheet.
SAFETY
Contains 2-Butanone oxime. May produce an allergic reaction. Labelling in accordance with EU directive 67/548
SHELF LIFE
18 months from manufacturing date, see above for expiry date.
STANDARDS
ISO 11600 F&G LM - Primerless on glass, aluminium and concrete.
COLOUR RANGE
Clear, Brilliant White, Teak, Brown, Black, Caramel, Bronze, Toffee, Grey, Dark Grey, Alu-Grey, Anthracite Grey RAL 7016, Buff, Portland, Beige, Stone, Oak, Light Brown, Dark Brown, Rustic, Red/Terracotta, Basalt Grey RAL 7012. For an extensive range of RAL colours.
Everbuild 450 Builders Silicone - Grey
Description : 450 Builders Silicone is a premium quality low modulus non-corrosive neutral cure silicone sealant that adheres to virtually all substrates, both porous and non-porous.
Typically used for construction expansion joints and perimeter pointing of all types of door and window frames.
Conforms to ISO 11600 class: F 25LM.
Benefits
• Excellent adhesion - adheres to most common surfaces including glass, metals, plastics and wood
• Low dirt pick up - important in PVCu work
• Excellent flexibility - +/- 25%.
• High resistance to plasticiser migration - may be used over water based and solvent based paints.
• Excellent external weathering properties.
• Suitable for use on polycarbonate
• Certified under the harmonized European standard EN15651 for façade, glazing, cold climate and sanitary applications in compliance with the Construction Product Regulation
• FDA approved under code CFR 21. 177.2600(e)
Areas For Use
• Perimeter pointing internally and externally around PVCu /wood and all other window frames.
• Sealing and as an adhesive onto PVCu, plastic trims and components.
• Bedding insulated glass units in accordance with relevant clauses of BS8000 Part 7.
• Suitable as an expansion joint sealant.
• Weather sealing and joint sealing to pre-formed panels.
• Sealing soft metals such as lead, copper and zinc.
• General glazing sealing and draughtproofing, including repair work over existing sealant.
• Glass to glass and glass to aluminium sealing.
• Parapet and roof weather sealing applications.
Limitations
• Do not use in conjunction with bitumen asphalt, neoprene and certain organic elastomers.
• Do not use in the manufacture of Aquariums. Use AQUA MATE
• Do not use on substrates that bleed oil, solvents or plasticisers.
• Non overpaintable. Use WEATHER MATE.
• Use as a mirror adhesive; Not recommended- Use MIRROR MATE.
Everbuild 450 Builders Silicone - Premium Oak
Description:
450 Builders Silicone is a premium quality low modulus non-corrosive neutral cure silicone sealant that adheres to virtually all substrates, both porous and non-porous.
Typically used for construction expansion joints and perimeter pointing of all types of door and window frames.
Conforms to ISO 11600 class: F 25LM.
Everbuild 700T Silicone Caramel
Silicone 700T is a fast, neutral cure, low modulus sealant specially formulated for the PVCu and roofline industry.
For perimeter pointing window and door frames, sealing plastic roofline areas and general weathersealing. Now contains a powerful anti-fungal compound.
Soudal Silicone Sealant Low Modulus Neutral Cure - Brown
- Neutral Silicone
- Low Modulus
APPLICATION
Premium grade, one part, neutral curing, silicone sealant for glazing, constructions and industrial applications. Perimeter sealing of wood, PVCu and aluminium widnow and door frames. Sealing of roofline and drainage systems. Weathersealing of aluminium glazing systems, curtain walling and facade panels. Can be used in direct contact with all types of glass, except self-cleaning types (use SOUDAL SMX 506 for this application). Bedding of double glazed sealed units in wet glazing applications*. Sealing of expansion and movement joints in construction. roofing seals including lead roofing slates, and fibre-cement. Industrial sealing applications; coated metals, anodized aluminium, stainless steel. HVAC ducting, pipework, and drainage joints. general maintenance and sealing of cars, caravans, mobile homes and boats.
*Due to the number of sealed unit sealants available, a prior compatibility test is recommended.
CHARACTERISTICS
Fast curing neutral silicone (very low dirt pick up).
Solvent free silicone, no shrinkage during curing. Virtually odourless. Thick-bodied formulation for ease of use. Excellent break off and tooling, Excellent primerless adhesion on all common construction materials, (glass, plastics, masonry substrates, metals and wood). For natural stone applications we recommend the use of SILIRUB MA. Resistant to UV, rain, snow and ozone, and many chemicals. Low modulus of elasticity, high movement capability. Independently tested to ISO 11600 F&G 25 LM standard (test reports - IFT Rosenheim 504 35398/1, 504 35398/2. High and low temperature resistance (from -40ºC up to 200ºC).
DIRECTIONS FOR USE
Surfaces to be sealed must be dry, clean and free of dust, grease and other contaminants. Apply at temperatures between +5ºC and +40ºC. for more detailed information consult the technical data sheet.
SAFETY
Contains 2-Butanone oxime. May produce an allergic reaction. Labelling in accordance with EU directive 67/548
SHELF LIFE
18 months from manufacturing date, see above for expiry date.
STANDARDS
ISO 11600 F&G LM - Primerless on glass, aluminium and concrete.
COLOUR RANGE
Clear, Brilliant White, Teak, Brown, Black, Caramel, Bronze, Toffee, Grey, Dark Grey, Alu-Grey, Anthracite Grey RAL 7016, Buff, Portland, Beige, Stone, Oak, Light Brown, Dark Brown, Rustic, Red/Terracotta, Basalt Grey RAL 7012. For an extensive range of RAL colours.
Soudal Silicone Sealant Low Modulus Neutral Cure - Clear
- Neutral Silicone
- Low Modulus
APPLICATION
Premium grade, one part, neutral curing, silicone sealant for glazing, constructions and industrial applications. Perimeter sealing of wood, PVCu and aluminium widnow and door frames. Sealing of roofline and drainage systems. Weathersealing of aluminium glazing systems, curtain walling and facade panels. Can be used in direct contact with all types of glass, except self-cleaning types (use SOUDAL SMX 506 for this application). Bedding of double glazed sealed units in wet glazing applications*. Sealing of expansion and movement joints in construction. roofing seals including lead roofing slates, and fibre-cement. Industrial sealing applications; coated metals, anodized aluminium, stainless steel. HVAC ducting, pipework, and drainage joints. general maintenance and sealing of cars, caravans, mobile homes and boats.
*Due to the number of sealed unit sealants available, a prior compatibility test is recommended.
CHARACTERISTICS
Fast curing neutral silicone (very low dirt pick up).
Solvent free silicone, no shrinkage during curing. Virtually odourless. Thick-bodied formulation for ease of use. Excellent break off and tooling, Excellent primerless adhesion on all common construction materials, (glass, plastics, masonry substrates, metals and wood). For natural stone applications we recommend the use of SILIRUB MA. Resistant to UV, rain, snow and ozone, and many chemicals. Low modulus of elasticity, high movement capability. Independently tested to ISO 11600 F&G 25 LM standard (test reports - IFT Rosenheim 504 35398/1, 504 35398/2. High and low temperature resistance (from -40ºC up to 200ºC).
DIRECTIONS FOR USE
Surfaces to be sealed must be dry, clean and free of dust, grease and other contaminants. Apply at temperatures between +5ºC and +40ºC. for more detailed information consult the technical data sheet.
SAFETY
Contains 2-Butanone oxime. May produce an allergic reaction. Labelling in accordance with EU directive 67/548
SHELF LIFE
18 months from manufacturing date, see above for expiry date.
STANDARDS
ISO 11600 F&G LM - Primerless on glass, aluminium and concrete.
COLOUR RANGE
Clear, Brilliant White, Teak, Brown, Black, Caramel, Bronze, Toffee, Grey, Dark Grey, Alu-Grey, Anthracite Grey RAL 7016, Buff, Portland, Beige, Stone, Oak, Light Brown, Dark Brown, Rustic, Red/Terracotta, Basalt Grey RAL 7012. For an extensive range of RAL colours.
Liniar Approved 700SC Silicone - Cream
Liniar Approved 700SC silicone offers a high quality finish to coloured installations.
Specially formulated to provide extra tool down time on longer joints. For expansion joints, perimeter pointing window and door frames, sealing roofline areas and general weather sealing.
Everbuild 700T Silicone Mahogany
Silicone 700T is a fast, neutral cure, low modulus sealant specially formulated for the PVCu and roofline industry.
For perimeter pointing window and door frames, sealing plastic roofline areas and general weathersealing. Now contains a powerful anti-fungal compound.
Colour: Mahogany
Everbuild 700T Neutral Cure Silicone Clear
Silicone 700T is a fast, neutral cure, low modulus sealant specially formulated for the PVCu and roofline industry.
For perimeter pointing window and door frames, sealing plastic roofline areas and general weathersealing. Now contains a powerful anti-fungal compound.
Our uPVC fascias and soffits from are designed as a cost effective and maintenance free solution for replacing existing old timber fascia boards. They are available in a wide range of colours and styles. Or for new installations. The fascia boards are thick enough to nail directly into the rafters of the roofs for quick and easy installations. Our range of BSI approved rooflines is is fully guaranteed and available for home delivery.
Guttering > 114mm Square Guttering - Brown
Floplast 65mm Brown Square Downpipe Bracket (RCS1V)
Description : Floplast Gloss Brown Square 65 mm Downpipe stand off clip, for use with Floplast 65mm Square Downpipe.
Manufacturer : Floplast
Colour : Brown
Floplast 65mm Brown Square Downpipe Adjustable Offset Bend (RBS5V)
Description : Floplast 112 degree Adjustable offset downpipe bend for use with Floplast 65mm square downpipes. This two piece offset bend can be cut to size, marked in increments of 5mm, from 25m to 65mm. Allowing for variable distances between the running outlet and the downpipe against the wall.
Manufacturer : Floplast
Colour : Brown
Floplast 65mm Brown Square Downpipe 112º Offset Bend (RBS2V)
Description : Floplast 112º offset downpipe bend for use with Floplast 65mm square downpipes. Normally bought in pairs and used to bring the downpipe from the running outlet in towards a wall and then back to a vertical postion.
Manufacturer : Floplast
Colour : Brown
Floplast 68mm Brown Round 2.5m Downpipe (RP2.5V)
Description : Floplast 68mm Gloss Brown 2.5m long Downpipe, fits straight into fixings
Manufacturer : Floplast
Colour : Brown
Dimensions : 68mm Diameter x 2.5m Length
Floplast 68mm Brown Round 4m Downpipe (RP4V)
Description : Floplast 68mm Gloss Brown 4m Downpipe, fits straight into fittings.
Manufacturer : Floplast
Colour : Brown
Dimensions : 68mm Diameter x 4m Length
